5 Ceiling Fans & LED Lighting Upgrade for a Setia Ecohill Bungalow

The Brief

Mr. and Mrs. Tan had been living in their Setia Ecohill bungalow for almost a decade. Their original ceiling fans were the white plastic kind that came with the developer package — noisy, slow, and three of them had started wobbling. The living room and dining were lit by harsh 6500K white fluorescents, which gave the house a "office at 9pm" feel after sunset.

They wanted two things from one visit: quieter, stronger fans across five rooms, and warmer, dimmable lighting in the social areas. They booked through our Semenyih electrician team after seeing a neighbour's recent fan installation in the same row.

What We Surveyed Before the Quote

Before quoting, we walked the house. Five rooms needed fans: living, dining, master bedroom, and two kids' rooms. The hook plates from the old fans were still in place — but in two rooms, the original boxes were the lightweight plastic ones meant only for ceiling roses, not heavier modern DC motors.

• Ceiling height ranged from 9 ft (bedrooms) to 11 ft (living, with a slight cathedral slope on one side).
• The lighting circuits were on a single MCB shared with several plug points — common in 2014-era Setia Ecohill builds. Dimmer compatibility had to account for that.
• Three of the five fan switches were standard rocker types; two had old-style 3-speed regulators that wouldn't play nicely with DC motors.

We sized fans by room: 56-inch DC fans for living and dining, 52-inch DC for the master and a kid's bedroom, and a quieter 48-inch for the smaller kid's room. The Tans had already shortlisted KDK and Acorn — we walked through the trade-offs and they settled on KDK U60FW for the larger rooms and Acorn DC222 for the smaller ones.

Day of Installation

We started at 9:30am and worked top-down: kids' rooms first (smallest fans, simplest wiring), then master, then dining, ending in the living room where the cathedral slope needed a downrod adjustment.

For each fan we:

• Removed the old fan, capped exposed live wires, then opened the ceiling box.
• Swapped the lightweight plastic boxes (rooms 2 and 4) for fan-rated metal boxes braced across the joists — non-negotiable for a 56-inch fan that will spin for the next 10 years.
• Replaced the speed regulator with the matching DC fan wall controller. The KDK U60FW takes a proprietary controller that pairs over RF, which we mounted in the existing switch box.
• Balanced each fan after first spin-up — we don't leave a fan that wobbles even slightly, because a wobble at speed 1 becomes a vibration at speed 6.

While the fans were being hung, our second electrician worked through the lighting in the living and dining areas: 18 existing 60W downlights swapped for 9W warm-white (3000K) dimmable LEDs, plus a trailing-edge dimmer at the entry switch. Two of the kitchen pendants were also re-balanced — one had been pulling its conduit since a previous DIY install.

What We Found Mid-Job

Two things worth noting for similar Setia Ecohill homes:

• One of the old AC fan motors had been drawing ~85W and running hot for years. The wiring at the rose was discoloured. We cut back to clean copper and re-terminated — a quiet failure that nobody would have spotted until something melted.
• The cathedral living-room slope needed a 12-inch downrod (not the standard 6-inch). KDK ships the 6-inch by default; we keep 12-inch and 18-inch downrods in the van for this exact reason. No second trip needed.

The Result

By 5:30pm, all five fans were spinning silently, the living and dining areas glowed warm at the touch of a dial, and we'd left the house cleaner than we found it. The Tans noticed the noise difference immediately — Mrs. Tan said she could finally hear the TV at normal volume.

What This Job Tells Us About Setia Ecohill Bungalows

Setia Ecohill homes from the 2013-2016 phases share a few habits — lightweight ceiling boxes in two of the five rooms, mixed-load lighting circuits, and rocker-style switches that don't tolerate modern dimming. None of it is a fault — but it means a fan-and-light refresh on a 10-year-old home isn't just "swap and screw". We see this pattern across Setia Ecohill, Eco Majestic, and the older Bandar Rinching sections.

If you're planning a similar upgrade, two upstream services that pair well: ceiling fan installation (book per fan or per house), and lighting installation if you're moving downlights or adding feature lighting.
